LV Switchgear, also known as UL 1558 Low Voltage Switchgear, is a key low-voltage power distribution product used for receiving, distributing, controlling, and protecting electrical energy in low-voltage systems. It is commonly installed on the low-voltage side of transformers and serves as the primary distribution equipment for downstream switchboards, panelboards, motor control systems, lighting panels, power equipment, HVAC systems, pumps, and other electrical loads.
| Standard Reference | UL 1558, ANSI C37.20.1 |
|---|---|
| Circuit Breaker Type | UL1066 Air Circuit Breaker, ACB |
| Breaker Installation | Withdrawable type available |
| Номинальный ток | Project-based configuration; high-current busbar options available |
| Short-Circuit / Bus Withstand | Up to 100kA available according to project design |
| Установка | Indoor electrical room, power distribution center, substation, industrial facility |
Только типовая конфигурация. Окончательные номинальные характеристики подтверждаются с учетом требований проекта.
LV Switchgear / UL 1558 Low Voltage Switchgear is widely used in low-voltage power distribution systems that require high reliability, high current capacity, and safe operation. It is typically installed after a transformer and acts as the main low-voltage distribution center for electrical loads.
